Micro-World Gems & Gemology, Fall 2019, Vol. 55, No. 3

Iolite-Sunstone Intergrowth and Inclusions

Iolite-sunstone overgrowth crystal specimen.
Figure 1. An iolite-sunstone overgrowth crystal specimen. Photo by Kevin Schumacher.

At the GIA Carlsbad laboratory, the authors recently examined a cabochon of “bloodshot” iolite (containing red, eye-visible platelets of hematite) intergrown with a sunstone (figure 1). This material was reportedly sourced from India. Cordierite (iolite) and plagioclase feldspar is a common metamorphic mineral assemblage, and similar material reportedly from India has been documented in the past (Winter 1991 Gem News, pp. 261–262).

This “double” gem specimen displays a mixture of an attractive bluish violet dichroic color with red hematite platelet inclusions in the iolite half, combined with an orange aventurescence effect from numerous tiny copper-colored hematite platelets in the sunstone half.

An anthophyllite crystal inclusion exhibits high transparency.
Figure 2. This colorful inclusion scene showcases an anthophyllite crystal inclusion, which exhibits high transparency, several cleavage planes, and a thin/bladed prismatic crystal form. Photomicrograph by Jonathan Muyal; field of view 2.34 mm.

Viewing the stone under magnification offers an inclusion scene with a variety of well-formed hematite platelets, crystals, and liquid inclusions. Of particular interest was a fine elongated single-crystal inclusion of anthophyllite (figure 2).

The crystal shape of the anthophyllite could easily be mistaken for phlogopite, which has been documented in cordierite (E.J. Gübelin and J.I. Koivula, Photoatlas of Inclusions in Gems, Vol. 1, ABC Edition, Zurich, 1986, p. 268). In fact, several greenish brown prismatic phlogopite crystal inclusions were also observed inside the same specimen. Nevertheless, the anthophyllite crystal was conclusively identified by Raman microspectrometry analysis. The anthophyllite crystal inclusion showed a bladed prismatic crystal form, orangy yellow color, transparency, and several cleavage planes.

Although amphibole mineral inclusions have been documented extensively, distinct prismatic anthophyllite crystal inclusions are very rare and few references are found in the literature. Anthophyllite is more common in lamellar or fibrous form, classified as asbestos.

This combination iolite-sunstone specimen and its inclusions offer a unique visual composition that makes it a desirable piece for a gem collection

Jonathan Muyal is a former staff gemologist, and Paul Mattlin is manager of distance education, at GIA in Carlsbad, California.
